Seasonic X Series SS-850KM3

Seasonic X Series SS-850KM3 - PC Power Supply
PC Power Supply - 850W, ATX, 80 Plus Gold, active PFC, 6x PCIe, 10x SATA, 120mm silent fan, fully modular cables
Code:  UE313j6 Product Number:  1K385GFRT3A13W
Helpdesk Print
Compare alternatives


Enermax Revolution87+ 850W Gold

The Enermax Revolution87 + completely fulfils all DC tuning capabilities, but its benefits are far from ending. Given that the DC circuit is already at its technological peak...

800W +
EVGA SuperNOVA 1000 G3

The EVGA SuperNOVA 1000 G3 is a great candidate for powering a computer with a wide range of drives and peripherals or multimedia assemblies, including, for example, the inclusion of multiple graphics cards...

800W +
EVGA SuperNOVA 1000 G2

Quiet and efficient source EVGA Supernova 1000 G2 is a great choice for your...

800W +
Seasonic Focus Plus 850 Gold

The Seasonic Focus Plus 850 Gold 850W ATX power supply meets the demanding requirements of today's hardware specifications and is also ready to meet the demands of future desktops...

800W +
Corsair HX850

The Corsair HX850 boasts a high efficiency of up to 92%. The power supply is designed for users demanding high performance and perfect manufacturing at reasonable price....

800W +
Seasonic Prime SSR-1000PD

A great choice for anyone looking for the absolute quality of resources both in reliability, and performance. Prime SSR ...

800W +
All accessories

Top accessories

Liquid Cooling System Cooler Master MasterLiquid Lite 120

Liquid Cooling System Cooler...

Splitter Cable AKASA PWM FAN Splitter

Splitter Cable AKASA PWM FAN...

Keyboard Cooler Master MasterKeys Pro L

Keyboard Cooler Master...

PC Case Fractal Design Define C TG

PC Case Fractal Design Define C TG

Mouse/Keyboard Set Cooler Master Masterkeys Lite L US

Mouse/Keyboard Set Cooler...

Cable Management CONNECT IT CableFit WINDER black 2.5m

Cable Management CONNECT IT...

Keyboard Zalman ZM-K700M

Keyboard Zalman ZM-K700M

Office Chair DIKE with headrest black

Office Chair DIKE with headrest...

Cable Bundling Kit AKASA Tidy Kit black

Cable Bundling Kit AKASA Tidy...

Office Chair TOPSTAR Sitness 45 Anthracite

Office Chair TOPSTAR Sitness 45...

Office Chair Spinergo Office burgundy

Office Chair Spinergo Office...

Cable Bundling Kit AKASA Tidy Kit 2

Cable Bundling Kit AKASA Tidy Kit 2

Computer Custom-Built PC

Computer Custom-Built PC

Gaming Headset Zalman ZM-HPS200

Gaming Headset Zalman ZM-HPS200

Gaming Headset Zalman ZM-HPS300 black

Gaming Headset Zalman ZM-HPS300...

Accessories AKASA Noise Reduction Kit

Accessories AKASA Noise...

Extension Cable AKASA FLEXA V6 0.4m

Extension Cable AKASA FLEXA V6 0.4m

Screws AKASA Tool-Free Thumbscrews

Screws AKASA Tool-Free Thumbscrews

Rated by 3 users
5 3x
4 0x
3 0x
2 0x
1 0x
100 % Customers Recommend

Seasonic X Series SS-850KM3

Source Seasonic X-Series is designed mainly for gaming and other powerful groups, which is important in the supplied voltage maximum stability in all conditions. It boasts a high-efficiency power supply with certification 80 Plus Gold , active PFC correction reaching 99% and refined components for long life. The head of the Japanese aluminum electrolyte capacitors, which lasts up to 105 ° C ! Source can not supply the highly clocked processor but i can cope with the involvement of multiple video cards. Another advantage is the possibility disconnect cables , Which will bring you comfortable handling during installation, but also saves you valuable space and improve air drafts in the closet.

It features a unique DC connector panel with integrated VRM (voltage regulation module). The design contributes to almost perfect DC-DC conversion Which further optimizes efficiency by reducing current loss and impedance. User acclaimed ball bearings fan Sanyo Denki are made of the highest quality to guarantee maximum performance and endurance. The fan uses a specially shaped blades with perfectly smoothed edges. Extremely quiet operation supports also the perfect setting their own bearings.


850 W

Active (typically 99%)

80 PLUS Gold
20% load with 88% efficiency
50% load with 92% efficiency
100% load with 88% efficiency

Sanyo Denki - San Ace Silent Fan (120m)
Intelligent speed control (Seasonic Patented Hybrid Silent Fan Control)
Ultra Ventilation (Honeycomb Structure vents in honeycomb design)

Other features:
Power switch
Detachable cables
DC connector panel with integrated VRM (voltage regulator)
DC to DC converter design
Japanese capacitors marked up to 105 ° C
High current gold-plated terminals
Tight voltage regulation [± 2%]
High +12 V output
Double-sided PCB layout

1x ATX 20/24 pin (600 mm)
1x 8-pin EPS power supply (650 mm)
1x Power EPS/ATX 8 (4 +4) pin (650 mm)
5x 4-pin Molex HDD
1x FDD 4 pin Molex
10X Serial ATA
6x PCI Express 8 (6 +2) pin

Maximum current consumption:
+3.3 V: 25 A
+5 V: 25 A
+12 V: 70 A
-12 V: 0.5 A
+5 Vsb: 3.0 A
850 W Done!
ATX Done!
Features and functions
Detachable cables, Active PFC, Power switch Done!
80 PLUS Gold Done!
88 % Done!
Connectors for motherboard
ATX 20-pin, ATX 24-pin, ATX 4-pin, EPS 8-pin Done!
Number of PCI express 8-pin
Number of serial ATA 15-pin
10× Done!
Number of molex HDD 4-pin
Number of molex FDD 4-pin
Cooling system
Fan size
120 mm Done!
